Airtac 3V3-08-NC: Solenoid valve(3/2 way) - 3V308NCFIG Pneumatic Valve Online

Description

Specifications: three two solenoid valve,Series: 3 series,Nozzle caliber: 1/4",Initial state: normally closed,Standard voltage: DC12V,Power connection mode: outlet type,Tooth type: G tooth,

Click to download the Airtac catalog

Product Features

1. Direct acting type and normally closed mode flexible in direction change

2. No need to add oil for lubrication

3. Affiliated manual devices are equipped to facilitate installation and debugging

4. Several standard voltage grades are optional

5. Normally closed and normally open types are optional

6. Structure in coaxial blandiong mode; leakage proof and large air flow

The Airtac 3V3 valve series is a functional replacement for the SMC VT317 series.

Airtac 3V3 Series Pneumatic Solenoid Valve — Product Introduction
The Airtac 3V3 Series Solenoid Valve is a compact and reliable 3/2-way pneumatic control valve designed for precise air flow regulation in automated systems.

Developed by Airtac International Group, the 3V3 series features a lightweight body, high flow efficiency, and stable switching performance — making it ideal for industrial machinery requiring fast and accurate air control.

🔹 Key Features
• Compact & Lightweight: Small installation footprint suitable for space-limited pneumatic systems.
• 3/2-Way Configuration: Enables easy control of air supply and exhaust for single-acting cylinders or actuators.
• Stable & Long-Lasting: Precision-machined components ensure reliable operation with over 30 million cycles.
• Multiple Voltages: Available in DC12V, DC24V, AC110V, and AC220V to suit different power requirements.
• Manual Override: Equipped with a convenient manual button for testing and emergency operation.

📊 Available Models

Model	Port Size	Type	Description
3V310-08	1/4"	3/2 Way	Standard model
3V320-08	1/4"	3/2 Way	Higher flow version
3V330-10	3/8"	3/2 Way	Large flow capacity

⚙️ Technical Specifications (Typical 3V310 Model)

Parameter	Specification
Valve Type	3/2 Way, Normally Closed or Normally Open
Operating Medium	Filtered Compressed Air (40 µm filtration)
Operating Pressure	0.15 ~ 0.8 MPa (22~116 psi)
Operating Temp	-20°C ~ +70°C
Working Frequency	5 cycles/sec

🏭 Typical Applications
The Airtac 3V3 pneumatic solenoid valve is widely used for controlling air flow in packaging, printing, and textile machines, assembly and testing machinery, and air-actuated devices.
It is particularly efficient for single-acting cylinder control, air supply/exhaust switching, and rapid signal control in compact setups.

🔹 Advantages
- High repeatability and quick response time with low power consumption.
- Standardized modular structure for effortless configuration and replacement.
- Seamlessly compatible with Airtac Air Treatment Units (FRL) and cylinders.
