Airtac RMTL series: magnetically coupled rodless cylinder - RMTL20X800SAT

Specifications: Magnetic coupling rod-less cylinder (precision guide rod type) Bore: 20mm Stroke: 800mm Magnet: with magnet Buffer mode: oil pressure buffer buffer 2 Tooth type: NPT tooth

Click to download Airtac product catalog

Product Features

1. Magnetic coupling rod-less cylinder, no mechanical connection between the piston and the slider, excellent sealing performance.

2. The movement of the piston is transmitted to the external slider through the magnetic coupling force, without the piston rod, saving installation space than the traditional cylinder, and can obtain a larger maximum stroke.

3. Both ends of the cylinder is equipped with a fixed buffer device, so that the reversing action is smooth and no impact, to prevent mechanical damage, optional external hydraulic buffer, buffer effect is better.

4. The piston cavity is isolated from the slider to prevent dust and dirt from entering the system and extend the service life of the cylinder.

5. Double guide rod structure, high guide precision, can withstand a certain lateral or eccentric load.
