AirTAC GPR40015H Precision Air Regulator
AirTAC GPR40015H Precision Air Regulator
Couldn't load pickup availability
The AirTAC GPR40015H is a precision air pressure regulator for a compressed-air line with PT 1/2 connections. Check the listed configuration and the catalog dimensions when selecting a replacement.
Product Features
- The precision regulator is designed for sensitive adjustment of downstream pressure.
- The catalog charts show how outlet pressure responds to inlet pressure and changes in flow.
- The body can be bracket-mounted or combined with compatible GAF and GPF air-preparation modules.
Technical Specifications
| Order code | GPR40015H |
|---|---|
| Working medium | Compressed air |
| Air ports | PT 1/2 |
| Regulator configuration | High pressure |
| Catalog sensitivity | Within 0.2% of full scale |
| Catalog repeatability | Within ±0.5% of full scale |
| Catalog air consumption | ≤11.5 L/min (ANR) |
| Mounting bracket | Included |
| Pressure gauge | Included (MPa / psi) |
| Maximum inlet pressure | 1.0 MPa |
| Outlet adjustment | 0.01–0.8 MPa |
| Ambient temperature | −20 to 70 °C |
Before You Order
Use the inlet and outlet markings to orient the unit. Check the drawing for the mounting pattern and leave access for adjustment or service.
Match the port thread to your existing fittings and confirm the operating range against your air supply and downstream requirements.
AirTAC calls for upstream particulate filtration and oil-mist separation. Choose the variant whose adjustment range includes the required set point.
Set the outlet pressure with the downstream equipment connected under its normal operating conditions. Check the gauge range and compare the catalog flow curve with the expected demand.
