Airtac GAFC300: Filter Regulator Lubricator - GAFC30010ASNT

Series: GA300 series conditioning combination Cup body material: PC cup Nozzle caliber: 3/8" Drainage mode: automatic drainage type Type: Standard Pressure gauge: not attached Filtration accuracy: 40μm level Dental type: NPT teeth (psi/bar) Reverse flow valve: without reverse flow valve

Specifications

1. Model: GAFC30010ASNT

2. Working medium: air, nozzle diameter: PT3/8, filter element accuracy: 40μm or 5μm, pressure regulating range: 0.15~0.9MPa(20 ~ 130psi)

3. Maximum operating pressure: 1.0MPa(145psi), guaranteed pressure resistance: 1.5MPa(215psi), operating temperature range:-5~70 ℃ (not frozen)

4. Filter cup capacity: 60CC, oil cup capacity: 98CC, recommended lubricating oil: ISO VG32 or equivalent oil, weight: 1020g

5. Pressure regulating filter components: GAFR300-10 and oil feeder components: GAL300-10. The nozzle type is optional with G teeth and NPT teeth.

Internal structure: 1.GA series pressure regulating filter/2. Connecting bracket/3.GA series oil feeder

Filter cartridge :GAFC300-40 With white 40μm filter element GAFC300-5 With blue 5μm filter element ， Filter water cup oil cup :GAFC300 Water Cup Metal Cup GAFC300 Oil cup

Click to download Airtac product catalog

Product Features

1. Fast and reliable installation fixture, easy to install and use.

2. Reliable pressure regulation performance and high precision.

3. High efficiency of removing moisture and solid particles.

4. There are two types of drainage: semi-automatic drainage and automatic drainage.

5. The bowl body has three materials to choose from: PC nylon and metal.

The Airtac GAFC200-600 air preparation series is a functional alternative to the SMC AC20A-40A series.
