AirTAC 6V21008A050 Solenoid Valve
AirTAC 6V21008A050 Solenoid Valve
Couldn't load pickup availability
The AirTAC 6V21008A050 is a 5/2-way pneumatic solenoid valve with PT 1/4 and a 220 V AC coil. It switches the compressed-air supply and exhaust for directional control of a pneumatic actuator.
Product Features
- A single coil shifts the spool and the spring returns it when power is removed.
- The extruded aluminum alloy body routes pilot exhaust to the shared R and S exhaust ports.
- The terminal connector can be installed in either orientation to suit the available wiring clearance.
- Threaded ports allow direct plumbing. AirTAC also provides matching manifold options for grouped installations.
Technical Specifications
| Order code | 6V21008A050 |
|---|---|
| Supply P and working ports A / B | PT 1/4 |
| Exhaust R / S | PT 1/8 |
| Catalog flow coefficient | Cv 0.91 |
| Body size series | 6V200 |
| Valve function | 5/2-way |
| Solenoid arrangement | Single solenoid, spring return |
| Actuation | Internal pilot |
| Working medium | Compressed air filtered through a 40 µm element |
| Operating pressure | 0.15–0.8 MPa |
| Proof pressure | 1.2 MPa |
| Catalog temperature | −20 to 70 °C |
| Body material | Extruded aluminum alloy |
| Lubrication | No added oil required |
| Pilot exhaust | Centralized through R / S |
| Maximum actuation frequency, no load | 5 Hz |
| Coil voltage | 220 V AC |
| Coil power | 1.1 VA |
| Coil supply tolerance | +15% / −10% |
| Electrical entry | Terminal, horizontal or vertical plug orientation |
| Lead length | 0.5 m |
| Coil protection | Dustproof |
| Coil insulation | Class F |
| Catalog coil activation time | ≤0.05 s |
Before You Order
Match the full order code, spool function, coil voltage and lead length to the control system. For 5/3-way control, check the center-position symbol against the intended actuator behavior.
Use the dimension drawing to check working ports, exhausts and connector clearance. Verify the pipe-thread standard on the mating fittings before ordering.
