AIRTAC MPG10X30SN Compact Panel Cylinder

Product Overview

The AIRTAC MPG10X30SN is a compact, double-acting pneumatic panel cylinder designed for applications with limited installation space. It features a 10 mm bore, 30 mm stroke, built-in magnet, and a plain piston rod without an end thread.

Its lightweight, flat-profile construction makes it suitable for small automation mechanisms, electronic assembly equipment, packaging machinery, inspection fixtures, and other applications requiring short linear motion.

Model Number Explanation

MPG10X30SN can be interpreted as follows:

• MPG: Standard panel cylinder, double-acting

• 10: 10 mm bore

• 30: 30 mm stroke

• S: Built-in magnet for piston position sensing

• N: Plain piston rod without an end thread

• Blank mounting code: Basic model without mounting accessories

Technical Specifications

• Click to download the MPG Airtac catalog

Specifications should be verified against the product label and the latest AIRTAC catalogue for the relevant market before ordering or installation.

Key Features

• Compact, flat-profile body for space-saving installation

• Double-acting operation for powered extension and retraction

• 10 mm bore and 30 mm stroke

• Built-in magnet for piston position detection

• Sensor mounting grooves integrated into the cylinder body

• High-precision piston rod guidance

• Rubber cushioning helps reduce end-of-stroke impact

• Lightweight construction for small automation mechanisms

• Normally operates without additional lubrication

• Multiple optional mounting accessories are available

Operating Principle

The MPG10X30SN is a double-acting pneumatic cylinder. Compressed air is supplied alternately to its two ports:

• Air supplied to one port extends the piston rod.

• Air supplied to the opposite port retracts the piston rod.

• A directional control valve is normally used to control the movement.

The built-in magnet allows compatible magnetic sensors to detect the piston position. The “S” designation indicates that the cylinder contains a magnet; it does not necessarily mean that a magnetic sensor is included.

Theoretical Extension Force

The 10 mm bore provides a piston area of approximately 78.5 mm². The theoretical extension force is approximately:

These values are theoretical and do not account for seal friction, back pressure, pressure loss, or external resistance. The actual usable force will be lower, and an appropriate safety factor should be applied during selection.

The retraction force is also lower than the extension force because the piston rod reduces the effective pressure area.

Typical Applications

The AIRTAC MPG10X30SN is suitable for:

• Small-part positioning

• Component pushing and ejecting

• Electronic assembly equipment

• Packaging and labelling machinery

• Inspection and testing fixtures

• Pneumatic clamping mechanisms

• Compact pick-and-place systems

• Small material-handling equipment

• Automated mechanisms requiring piston position feedback

Piston Rod Configuration

The “N” code means that the piston rod end has no thread. This configuration is suitable when the mechanism connects to or contacts a plain rod directly.

If the application requires a threaded connection for a rod-end accessory, floating joint, or mounting nut, the threaded-rod version should be selected instead. For example, MPG10X30S has the same bore, stroke, and built-in magnet but uses a male-threaded piston rod end.

Installation and Selection Notes

• Confirm that the 10 mm bore provides sufficient force for the load.

• Allow a suitable safety margin rather than selecting the cylinder based only on theoretical force.

• Confirm that the required travel is 30 mm.

• Ensure that a plain, unthreaded piston rod is suitable for the mechanism.

• Use fittings compatible with the M3 × 0.5 ports.

• Use clean, filtered compressed air.

• Install flow-control valves when speed adjustment is required.

• Avoid applying excessive radial or side loads to the piston rod.

• Add an external guide if the mechanism generates significant lateral force.

• Select compatible magnetic sensors separately when position detection is required.

• Prevent moisture inside the cylinder from freezing.

• Depressurize the system before installation, removal, or maintenance.

Product Summary

The AIRTAC MPG10X30SN is a double-acting compact panel cylinder with a 10 mm bore and 30 mm stroke. It includes a built-in magnet for position sensing and uses a plain piston rod without an end thread.

Its compact dimensions, low weight, integrated sensor grooves, and reliable linear movement make it a practical choice for small industrial automation systems where installation space is limited.
