Airtac CPV10 Micro-solenoid valve3/2 way AC220V-CPV10AP-200(CPV10AP200)
Airtac CPV10 Micro-solenoid valve3/2 way AC220V-CPV10AP-200(CPV10AP200)
Couldn't load pickup availability
Product Overview
Series: AirTAC CPV10S Series Solenoid Valve（CPV10AP200）
Voltage: Standard voltage is AC 220V
Wiring Type: Plug-in type connection
Terminal Wire Length: Equipped with Type 200; length is 2m (2000mm)
Description
The CPV10 series is a miniature 3-port 2-position (3/2 Way) direct-acting solenoid valve developed by AirTAC. This series is characterized by its ultra-compact size, rapid response, and low power consumption. it is ideally suited for integration into space-constrained automation equipment, medical instruments, or micro-pneumatic control systems.
Core Product Features
Safety Protection Design: Features a built-in surge suppressor to effectively prevent damage to the solenoid valve caused by surge voltages.
Non-Polarity Input: DC circuits utilize a non-polarity input design. The terminal wire can be freely adjusted in horizontal or vertical directions to meet specific installation requirements.
Silent Operation: AC specifications employ a bridge rectifier for full-wave rectification, significantly eliminating the "humming" noise typically associated with AC power operation.
Long Life & Low Starting Voltage: Engineered with low starting voltage requirements and a high-durability design for an extended service life.
Convenient Manual Debugging: Equipped with a manual override that includes a LOCK design, facilitating easy testing and troubleshooting during the installation and commissioning phases.
Detailed Technical Specifications
| Item | Technical Specifications |
| Acting Type | Direct-acting |
| Position & Way | 3 Port 2 Position |
| Orifice Size | Φ0.55mm |
| Effective Area | P→A: 0.25mm²(Cv=0.014); A→R: 0.35mm²(Cv=0.02) |
| Working Pressure Range | 0～0.8MPa (0～114psi) |
| Proof Pressure | 1.2MPa (175psi) |
| Operating Temperature | -20°C to 70°C |
| Response Time | Open < 7ms; Close < 7ms |
| Standard Voltage | AC 220V, AC 110V, DC 24V, DC 12V |
| Power Consumption | DC: 0.7W; AC: 1.5VA |
| Protection / Heat Resistance | Dustproof / Class F |
| Weight | Main Body: 15g; Screw: 0.46g |
