Airtac CDA: Solenoid Valve Coil - CDA092B

Coil category: DIN socket coil Coil inner diameter: coil specification (inner diameter ø9.0mm) Standard voltage: DC24V

Click to download Airtac product catalog

Product Features

solenoid valve gasket coil specification

Suitable for 4M210, 4M220, 4M310, 4M320.

Suitable for 4V210, 4V220, 4V230, 4V310, 4V320, 4V330, 4V410, 4V420, 4V430.

For 3V210, 3V220, 3V310, 3V320

Series (9.0mm Orifice Solenoid Valve): Available in terminal and gasket coil types.

Multiple voltage options:(A: AC220V),(B: DC24V),(C: AC110V),(E: DC24V),(F: DC12V)

1. There is a polarity indication on the connection terminal of the DC coil. Wiring instructions: "1" is connected to the positive terminal and "2" is connected to the negative terminal.

2. If the connection is wrong, the indicator will not light up, but the valve can still work normally.
